Why Two Identical Cells Are Never Truly Identical

No two battery cells are identical. Even from the same production line, cells differ slightly in capacity, internal resistance, self-discharge and open-circuit voltage — the cumulative result of tiny variations in materials, coating thickness, fill volume and formation. For a single cell these differences are invisible. Put several in a series pack and they become the difference between a battery that lasts years and one that fails in months. This article explains the discipline of grading and matching that separates reliable NiMH packs from unreliable ones.

What Gets Measured on the Grading Line

After formation, every cell passes through a measurement and sorting stage. The key parameters captured are:

• Capacity (mAh/Ah) — measured on a controlled discharge; cells are binned into grades (e.g. A, B, C) so a pack can be built from closely matched capacities.

• Internal resistance (AC-IR and DC-IR) — measured at a reference frequency or under pulse load; matched IR prevents pack imbalance and unequal heating.

• Open-circuit voltage (OCV) — a quick screen for gross defects and state-of-charge consistency.

• Self-discharge / leakage — a storage test identifies high-leakage cells that would drag a pack down when idle.

• Pressure and leak integrity — confirms seals and vents before cells leave the line.

Why Matching Matters in Series Packs

In a series string, current flows equally through every cell, but each cell's stored energy and resistance differ. The weakest cell governs the pack:

• Capacity mismatch — the lowest-capacity cell hits empty first; in a series string that cell can be driven into deep discharge and even reverse polarity, damaging it permanently.

• Resistance mismatch — a high-resistance cell heats more under load, ages faster, and imposes extra voltage sag.

• Self-discharge mismatch — a leaky cell discharges faster, becoming the weak link during standby.

Matching cells by capacity and internal resistance within a tight tolerance (manufacturers typically match to a few percent) dramatically improves pack balance, reliability and cycle life.

Grading Tolerances: How Tight Is Tight Enough?

The required matching tolerance depends on the application:

• Consumer and general packs — moderate matching (a few percent capacity spread) is sufficient and cost-effective.

• High-rate and power tools — tighter IR matching matters because load is high and imbalance stresses cells quickly.

• Backup and standby strings — tight capacity and self-discharge matching ensures the string stays balanced during long idle.

• Premium / industrial — narrow bands on both capacity and IR, with documented test data per cell.

Tighter matching costs more (more cells rejected or re-binned), so good pack designers specify the tolerance that meets the reliability target without overpaying.

Matching Strategies at Pack Assembly

How matched cells are grouped is as important as the match itself:

• Grading bins first — cells are binned by capacity and IR; a pack is built from cells drawn from the same bin, not from random stock.

• Series strings from one bin — all series-connected cells should come from the same grade to avoid the weak-cell problem.

• Parallel banks balanced — parallel cells should also be matched so no single cell carries disproportionate current.

• Documented traceability — a traceable record linking each pack to its cell test data enables root-cause analysis when a field issue appears.

The Role of Test Data in Pack Quality

Matching is not just about sorting; it is about data. A reputable pack supplier can show you the distribution of capacity and IR for the cells in your pack — evidence that the pack was actually balanced, not assembled from whatever was in stock. This data is also the foundation of statistical process control: if the capacity spread of cells from a line narrows, the process is stable; if it widens, something upstream has drifted.

Common Mistakes That Undermine Matching

• Random cell selection — assembling packs from ungraded stock guarantees imbalance and premature end-of-life.

• Mixing grades in one string — the weak cell always fails first and can take the pack with it.

• Ignoring IR — matching capacity alone misses resistance-driven imbalance and heating.

• Skipping self-discharge screening — a leaky cell surfaces only months later as a dead pack.

• No traceability — when a pack fails, there is no way to trace which cell or batch caused it.

Balancing Systems: Do You Still Need Them?

Matching reduces imbalance, but it does not eliminate the need for care in operation. In a series NiMH pack, a charge/discharge management layer — proper ΔV/ΔT charge termination, low-voltage cutoff, and periodic controlled full discharge to re-equalize — keeps matched cells aligned over their life. Matching and management work together: good cells and good electronics are a partnership, not either/or.
